Lenze E84AYCEC - Manual (Page 84)

E84AYCEC communication manual (Ethernet POWERLINK)
Index table
84
L
EDS84AYCEC EN 3.0 - 09/2012
0x1405.2 PDO_RxCommParam_05h_REC MappingVersion_U8 U8 R Version of PDO mapping 0
0x1600.0 PDO_RxMappParam_00h_REC NumberOfEntries U8 RW C13860/1
0x1600.1
...16
PDO_RxMappParam_00h_REC ObjectMapping_U64 U64 RW -
0x1601.0 PDO_RxMappParam_01h_REC NumberOfEntries U8 RW C13860/2
0x1601.1
...16
PDO_RxMappParam_01h_REC ObjectMapping_U64 U64 RW -
0x1602.0 PDO_RxMappParam_02h_REC NumberOfEntries U8 RW C13860/3
0x1602.1
...16
PDO_RxMappParam_02h_REC ObjectMapping_U64 U64 RW -
0x1603.0 PDO_RxMappParam_03h_REC NumberOfEntries U8 RW C13860/4
0x1603.1
...16
PDO_RxMappParam_03h_REC ObjectMapping_U64 U64 RW -
0x1604.0 PDO_RxMappParam_04h_REC NumberOfEntries U8 RW C13860/5
0x1604.1
...16
PDO_RxMappParam_04h_REC ObjectMapping_U64 U64 RW -
0x1605.0 PDO_RxMappParam_05h_REC NumberOfEntries U8 RW C13860/6
0x1605.1
...16
PDO_RxMappParam_05h_REC ObjectMapping_U64 U64 RW -
0x1800.0 PDO_TxCommParam_00h_REC NumberOfEntries U8 R - 2
0x1800.1 PDO_TxCommParam_00h_REC NodeID_U8 U8 R Node ID of the receiver 0 (pseudo
node ID for
PRes-Tx)
0x1800.2 PDO_TxCommParam_00h_REC MappingVersion_U8 U8 R Version of PDO mapping 0
0x1A00.0 PDO_TxMappParam_00h_REC NumberOfEntries U8 RW C13859/1
0x1A00.1
...16
PDO_TxMappParam_00h_REC ObjectMapping_U64 U64 RW -
0x1C0A.0 DLL_CNCollision_REC NumberOfEntries U8 R - 1
0x1C0A.1 DLL_CNCollision_REC CumulativeCnt_U32 U32 R -
0x1C0B.0 DLL_CNLossSoC_REC NumberOfEntries U8 R - 3
0x1C0B.1 DLL_CNLossSoC_REC CumulativeCnt_U32 U32 R -
0x1C0B.2 DLL_CNLossSoC_REC ThresholdCnt_U32 U32 R -
0x1C0B.3 DLL_CNLossSoC_REC Threshold_U32 U32 RW -
0x1C0F.0 DLL_CNCRCError_REC NumberOfEntries U8 R - 1
0x1C0F.1 DLL_CNCRCError_REC CumulativeCnt_U32 U32 R -
0x1C0F.2 DLL_CNCRCError_REC ThresholdCnt_U32 U32 R -
0x1C0F.3 DLL_CNCRCError_REC Threshold_U32 U32 RW -
0x1C10 DLL_CNLossOfLinkCum_U32 - U32 R -
0x1E40.0 NWL_IpAddrTable_0h_REC NumberOfEntries U8 R - 5
0x1E40.1 NWL_IpAddrTable_0h_REC IfIndex_U16 U16 R - 0
0x1E40.2 NWL_IpAddrTable_0h_REC Addr_IPAD U32 R C13000/1
0x1E40.3 NWL_IpAddrTable_0h_REC NetMask_IPAD U32 R C13001/1
0x1E40.4 NWL_IpAddrTable_0h_REC ReasmMaxSize_U16 U16 R Maximum frame size which can
be reconstructed from frames
arriving in fragments [byte].
1518
0x1E40.5 NWL_IpAddrTable_0h_REC DefaultGateway_IPAD U32 RW C13003/1
0x1E4A.0 NWL_IpGroup_REC NumberOfEntries U8 R - 3
0x1E4A.1 NWL_IpGroup_REC Forwarding_BOOL BOOL R Release for IP router function 0: FALSE
0x1E4A.2 NWL_IpGroup_REC DefaultTTL_U16 U16 RW TimeToLive value for transmitted
IP frames
Limits the range with regard to
router stations passed.
64
0x1E4A.3 NWL_IpGroup_REC ForwardingDatagrams_
U32
U32 R Counter for routed frames -
0x1F81.0 NMT_NodeAssignment_AU32 NumberOfEntries U8 R - 254
0x1F81.1
...100
NMT_NodeAssignment_AU32 NodeAssignment U32 RW C13028/1...100
0x1F81.240 NMT_NodeAssignment_AU32 NodeAssignment U32 RW C13029/1
EPL index Index name Subindex name Type Attr. Reference / description Value
