E84AYCEC communication manual (Ethernet POWERLINK)
Diagnostics
Diagnostic data
60
L
EDS84AYCEC EN 3.0 - 09/2012
9.3 Diagnostic data
 Pending diagnostic data are signalled from the controlled node to the managing node
by means of an emergency message.
 Code C13887 serves to suppress sending emergency messages to the managing node.
You can select which type of error is to be suppressed.
 Errors and warnings in the Inverter Drive 8400 and the plugged communication
module are sent to the managing node as extended diagnostic messages.
 The diagnostic data are visible via the PLC Engineering software.
Bytes Meaning Value [hex]
1 ... 6 Diagnostic block header 0x0010 001C 0100
7 ... 8 Alarm type 0x0001 (Diagnosis)
9 ... 12 API (Application Programming Interface) 0x0000 0000
13, 14 Slot number 0x0001 / 0x0002
15, 16 Subslot number 0x0001
17 ... 20 Module ID ID corresponding to module
21 ... 24 Submodule number ID corresponding to module
25, 26 Alarm specification 0xB000
27, 28 User structure ID 0x0001
29 ... 32 Error code
