Lenze E84AYCEC - Manual (Page 78)

E84AYCEC communication manual (Ethernet POWERLINK)
Parameter reference
Parameters of the communication module
78
L
EDS84AYCEC EN 3.0 - 09/2012
C13887
C13898
C13899
C13900
Parameter | Name:
C13887 | Suppress emergency message upon
Data type: BITFIELD_8
Index: 10688
d
= 29C0
h
This code serves to suppress sending alarm messages to the managing node. You can explicitly suppress a certain
type of error. Furthermore, all errors are entered into the logbook.
• A change can only be effective immediately if no error number with the error type selected here is active in
C00165.
Value is bit-coded:
Bit 0 Fault
Bit 1 Fault
Bit 2 Quick stop by trouble
Bit 3 Warning locked
Bit 4 Warning
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13898 | 0x1F9A Host Name
Data type: VISIBLE_STRING
Index: 10677
d
= 29B5
h
The code defines a DNS-compatible device name. The length is limited to 20 characters. The device name must be
non-ambiguous within the network domain.
Naming convention:
The device name ...
• starts with a letter;
• ends with a letter or a digit.
The device name consists of ...
• letters (A ... Z, a ... z);
• digits (0 ... 9);
• hyphen (-).
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13899 | 0x1F93.3 Node ID by SW
Data type: UNSIGNED_8
Index: 10676
d
= 29B4
h
This code serves to set the node ID by means of the software.
The value "0" is not a valid node ID. It serves to activate the setting via the rotary coding switches.
 Node address setting ( 38)
Setting range
(min. value | unit | max. value)
Lenze setting
0 239 0
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13900 | Firmware Type
Data type: VISIBLE_STRING
Index: 10675
d
= 29B3
h
Display of the Lenze firmware type of the communication module (product designation).
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
