E84AYCEC communication manual (Ethernet POWERLINK)
Error messages
Possible causes and remedies
EPL: Invalid module configuration [0x01bc6430]
EPL: State OPERATIONAL lost [0x01bc8131]
EPL: Invalid address selected [0x01bc8261]
EPL: Synchronisation lost from MN [0x01bc8265]
EPL: Telegram error detected (CRC) [0x01bc8266]
Response (Lenze setting in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Module configuration is faulty. Check the module configuration and correct it.
Response (Lenze setting in bold) Setting: C13880/1
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Data exchange via Ethernet POWERLINK has been
terminated.
• See also chapter " Interruption of Ethernet
POWERLINK communication " ( 52) .
• Check the network cable (plug) and replace it if
necessary.
• Connect the network cable to the Ethernet
POWERLINK terminals X251 or X252 and continue to
check the status of the managing node.
Response (Lenze setting in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
An invalid IP address has been assigned by the managing
node via Ethernet POWERLINK or set as node ID.
• Ensure that a valid IP address is assigned by the
managing node via Ethernet POWERLINK.
• Set valid node ID.
 Node address setting ( 38)
Response (Lenze setting in bold) Setting: C13880/2
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
In the controlled node, the synchronisation cycle of the
managing node has failed. The controlled node changes
automatically to the NMT_CS_PREOPERATIONAL_1
state and waits for a new run-up by the managing node.
• Check network cable and components (failure of
managing node, router).
• Restart managing node if required.
Response (Lenze setting in bold) Setting: C13880/3
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Faulty Ethernet frames (CRC error) have been detected.
Possible causes:
• A device in the network is not EPL-compliant.
• EMC interference is too strong.
• Check if a non-EPL-compliant device is in the network
(e.g. diagnostics PC).
• Reduce EMC interference on the network or use an
additional shield connection.
