E84AYCEC communication manual (Ethernet POWERLINK)
Technical data
General data and operating conditions
16
L
EDS84AYCEC EN 3.0 - 09/2012
4 Technical data
4.1 General data and operating conditions
Field Values
Order designation E84AYCEC
Communication profile Ethernet POWERLINK
Communication medium S/FTP (screened foiled twisted pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface RJ45: Standard Ethernet (according to IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Tree, star, and line
Node type Controlled node
Node addresses (node IDs) 1 … 239
Transmission mode Half duplex
Baud rate 100 Mbps
Voltage supply External supply via separate power supply unit
• "+": U = 24 V DC (20.4 V - 0 % ... 28.8 V + 0 %), I = 140 mA
• "-": Reference potential for external voltage supply
Conformities, approvals CE

Hardware manual for Inverter Drives 8400
Here you can find the ambient conditions and data on the electromagnetic
compatibility (EMC), which also apply to the communication module.
