E84AYCEC communication manual (Ethernet POWERLINK)
Technical data
Ethernet POWERLINK communication data
20
L
EDS84AYCEC EN 3.0 - 09/2012
4.3 Ethernet POWERLINK communication data
Communication time
The communication time is the time between the start of a request and the arrival of the
corresponding response.
The communication times in the Ethernet POWERLINK network depend on ...
 the processing time in the controller;
 the telegram runtime (baud rate / telegram length);
 the nesting depth of the network.
Processing time in the controller
There are no interdependencies between parameter data and process data.
Field Values
Min. cycle time 400 s
Total cycle times 0.4 / 0.5 / 1.0 / 2.0 / 3.0 … 20.0 ms
Buffer size • Tx-iso: max. 1490 bytes
• Rx-iso: max. 1490 bytes
(max. 32 bytes of PDO user data)
Delay time • Controlled node (T
Preq
- T
Res
): approx. 2.6 s
• Controlled node (T
SoA
- T
ASnd
): approx. 2.6 s
Frame size Max. asynchronous frame size (MTU): 1518 bytes
SDO communication method UDP/IP or ASND
Number of RPDOs Max. 6 channels
RPDO user data per application (all
RPDOs)
Max. 16 objects (max. 32 bytes)
Number of TPDOs 1 channel (data access of all nodes by broadcasting)
TPDO user data per application Max. 16 objects (32 bytes)
CN operating modes Support of ...
• Multiplex CNs
• Optional CNs
Data Processing time
Process data approx. 2 ms
+ 0 ... 1 ms
+ 1 ... x ms
Update cycle
Processing time in the module
Runtime of the application task of the technology
application used (tolerance)
Parameter data approx. 30 ms + 20 ms tolerance (typical)
• For some codes, the processing time may be longer (see software
manual/»Engineer« online help for the Inverter Drive 8400).
