E84AYCEC communication manual (Ethernet POWERLINK)
Parameter reference
Parameters of the communication module
C13901
C13902
C13910
C13915
Parameter | Name:
C13901 | Firmware Date
Data type: VISIBLE_STRING
Index: 10674
d
= 29B2
h
Display of the creation date of the communication module firmware
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13902 | Firmware Version
Data type: VISIBLE_STRING
Index: 10673
d
= 29B1
h
Display of the version number of the communication module firmware
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13910 | Last Module Error
Data type: UNSIGNED_32
Index: 10665
d
= 29A9
h
Display of the error code of the error last occurred in the communication module
Selection list
(Lenze setting printed in bold)
0 No error
297566817 Warning locked INVALID_ADDR
29122816 Software error
96239921 Fault OPER_LOST
230457649 Quick stop OPER_LOST
297566513 Warning locked OPER_LOST
431784241 Information OPER_LOST
96240229 Fault CN_SoC_LOSS
230457957 Quick stop CN_SoC_LOSS
297566821 Warning locked CN_SoC_LOSS
431784549 Information CN_SoC_LOSS
96240230 Fault COM_CRC
230457958 Quick stop COM_CRC
297566822 Warning locked COM_CRC
431784550 Information COM_CRC
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13915 | CustomerObject[16]
Data type: OCTET_STRING
Index: 10660
d
= 29A4
h
The code contains an octet string[16] for customised use.
Subcodes
Lenze setting Info
C13915/1 00000000000000000000000000000
000
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
