E84AYCEC communication manual (Ethernet POWERLINK)
Parameter reference
Parameters of the communication module
C13852
C13853
C13859
C13860
Parameter | Name:
C13852 | PDO words from MN
Data type: UNSIGNED_16
Index: 10723
d
= 29E3
h
The code indicates the PDO words received (from the managing node).
Subcodes
Info
C13852/1 wCtrl
C13852/2 wIn2
... ...
C13852/16 wIn16
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13853 | PDO words to MN
Data type: UNSIGNED_16
Index: 10722
d
= 29E2
h
The code indicates the PDO words sent (to the managing node).
Subcodes
Info
C13853/1 wState
C13853/2 wOut2
... ...
C13853/16 wOut16
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13859 | 0x1A00.0 Number of mapped Tx PDO-1
Data type: UNSIGNED_8
Index: 10716
d
= 29DC
h
Number of sent PDOs via the PDO channel 1 (Tx)
Display range
(min. value | unit | max. value)
0 16
Subcodes Info
C13859/1 0x1A00.0 Number of mapped Tx PDO-1
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13860 | 0x160x.0 Number of mapped Rx PDO
Data type: UNSIGNED_8
Index: 10715
d
= 29DB
h
Number of received PDOs via PDO channels 1 ... 6 (Rx)
Display range
(min. value | unit | max. value)
0 16
Subcodes Info
C13860/1 0x1600.0 Number of mapped Rx PDO-1
... ...
C13860/6 0x1605.0 Number of mapped Rx PDO-6
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
