Kinze 3660 Lift and Rotate Planter Rev. 7/14 User Manual
Page 9
TM
Model 3660
M0217-01
Rev. 7/11
1-3
Specifications
Specification
Conventional Hoppers
Number of Rows
12R N 30
16R N 30
Weight Empty (Mechanical)
15,040 lb ( 6,823 kg)
18,460 lb (8,374 kg)
Weight Empty (EdgeVac)
15,450 lb (7,008 kg)
18,400 lb (8,347 kg)
Transport Height
11' 11" (3.6M)
11' 11" (3.6M)
Planting Length
23' 9" (7.2M)
26'3" (8M)
Transport Length
39' 2" (12M)
49'2" (15M)
Planting Width
32' 11" (10M)
42'11" (13.1M)
Transport Width
11' 2" (3.4M)
11'2" (3.4M)
Seed Capacity
1.75 bu. (EdgeVac / Hopper); 1.90 bu. (Mechanical / Hopper)
Transport Tire Size
Four 41" x 11" R22.5 radial load range 'H' tubeless rib implement.
Field Tire Size
7.50" x 20" 8 ply tubeless rib implement tires.
Field Lift
Two master center rockshaft/four wing wheel slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
Specification
Air Seed Delivery (ASD)
Number of Rows
12R N 30
16R N 30
Weight Empty (Mechanical)
17,120 lb (7,766 kg)
20,020 lb (9,081 kg)
Weight Empty (EdgeVac)
17,450 lb (7,916 kg)
20,400 lb (9,254 kg)
Transport Height
12' 11" (4M)
12'11" (4M)
Planting Length
23' 9" (7.2M)
26'3" (8M)
Transport Length
39' 2" (12M)
49'2" (15M)
Panting Width
32' 11" (10M)
42'11" (13.1M)
Transport Width
11' 2" (3.4M)
11'2" (3.4M)
Seed Capacity
110 bu.
ASD Fill Height (planting position)
8' 5" (2.6M)
Transport Tire Size
Four 41" x 11" R22.5 radial load range 'H' tubeless rib implement.
Field Tire Size
7.50" x 20" 8 ply tubeless rib implement.
Field Lift
Two master center rockshaft/four wing wheel slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
TRACTOR HYDRAULIC REqUIREMENTS
Configuration
No Optional Pumps
Tractor Mounted Pump
2
Planter Mounted Pump
2
Mechanical Meter
3 SCV
20 gpm min.
EdgeVac Meter
1
4 SCV
40 gpm min.
3 SCV
25 gpm min.
ASD (with Mechanical Meter)
3
4 SCV
30 gpm min.
3 SCV
20 gpm min.
ASD (with EdgeVac)
3
5 SCV
50 gpm min.
4 SCV
40 gpm min.
3 SCV
25 gpm min.
1
External case drain required for EdgeVac hydraulic circuits when no optional pumps are used.
2
Pump PTO Requirements: Tractor mounted - 1000 rpm, 1⅜" diameter shaft. Planter mounted - 1000 rpm, 1¾"
diameter shaft.
3
Tractor Horsepower Requirement: 225 horsepower or greater class tractor is required to effectively operate a fully
optioned (ASD, Interplant, EdgeVac) 3660 planter.
