Model 3660 M0217-01
Rev. 8/12 5-43
Lubrication and Maintenance
ELECTRICAL WIRING HARNESS SCHEMATIC (On Planter)
23 Pin Capacity
Pin
“J”
Gr
ay (Do
wn Pressure Decrease)
Pin
“D”
Blue/White (Do
wn Pressure Increase)
Pin
“Q”
Blac
k (Blac
k Ground)
Pin
“W”
Or
ange/Blac
k (Compressor P
ow
er)
Pin
“H”
Blue (L.H.
Mar
ker) P
or
t V2
Pin
“O”
Red (R.H.
Mar
ker) P
or
t V1
Pin
“C”
Blac
k/Red (Ground)
Pin
“A”
Or
ange/Red (T
ongue)
P
or
ts V10, V13
& V14
Pin
“B”
Blue/Red (Rotate)
P
or
ts V9
& V12
Pin
“V’
Blue/Blac
k (Raise to
Tr
anspor
t) P
or
t V16
Pin
“V’
Blue/Blac
k (Raise to
Tr
anspor
t) P
or
t V16
Pin
“T”
Y
ello
w/Red (Ground) (12 Gauge)
Pin
“F”
Y
ello
w/Red (Wing Loc
k) P
or
ts
V3 &
V4
V J L
O S
T
U
Q R P
E
A
F
H
G
D
B
C
N
M
X W K
Valve block -
Located on hitch.
Valve block -
Located on rear center frame.
