INFICON BPG402-SE ATM to Ultra-High Vacuum Gauge (EtherCAT) - Manual (Page 27)

tira93e1 (2014-04) BPG402-SE.cp
27
Writing the corresponding password (vendor specified value) enables Access
Rights (Index F940 Subindex 03)
Index SI DataType NV Access PM Name
F940 0x01 UDINT RO Measurement Principle
0x02 BYTE RO Number of Sensors
0x03 USINT RO Access Rights
0x04 V_STRING x RO SW Version VPG PCB
F9F0 V_STRING RO Manufacturer Serial
Number
F9F1 0x01 UDINT RO CDP Functional
Generation Number
Module 1
0x02 RO CDP Functional
Generation Number
Module 2
F9F2 0x01 UDINT RO SDP Functional
Generation Number
Module 1
0x02 UDINT RO SDP Functional
Generation Number
Module 2
F9F3 V_STRING RO Vendor Name
F9F4 0x01 V_STRING RO Semiconductor SDP
Device Name Module 1
0x02 V_STRING RO Semiconductor SDP
Device Name Module 2
F9F5 0x01 USINT RW Output Identifier Module 1
0x02 USINT RW Output Identifier Module 2
F9F6 UDINT RO Time Since Power On
F9F7 UDINT x RO Time Total Powered
F9F8 UDINT RO Firmware Update
Functional Generation
Number
Measurement principle assigned to the object instance.
The most significant nibble of the parameter represents the sensor type of the first
Module, the second most significant nibble of the parameter represents the sensor
type of the second Module, and so forth.
Measurement Principle (Index F940)
1
2
3
4
5 Capacitance Manometer
Piezo
Heat Transfer
Cold Cathode
Hot Cathode
Number of Sensors (Index F940): In this device are 2 sensors implemented.
Subindex 0x02
4.7.15 Information Device
Subindex 0x01 (F940)
Subindex 0x02 (F940)
