If the bit "Underrange” is set, all modules of the gauge are in an underrange
condition.
The value copied from the measurement value of the active measuring module
used for the Input PDO.
Identifies the module that is providing the measurement value, the latter of which is
copied into the Active Value parameter for all Input PDO’s.
0 No module has a valid value
1 Heat Transfer sensor is providing the Active Value
2 Hot Cathode sensor is providing the Active Value
Index SI DataType NV Access PM Name
F641 0x01 UDINT RO tx Trip Point Output All
Instance
Status of Trip Point instances.
Trip Point Output All Instance
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4…31
Status High Trip (I 0x600E, SI 0x01)
Status Low Trip (I 0x600E S,I 0x02)
Status High Trip (I 0x600F, SI 0x01)
Status Low Trip (I 0x600F, SI 0x02)
0
Index SI DataType NV Access PM Name
F6F0 0x01 UDINT RO tx Input Latch Local
Timestamp module 1
0x02 UDINT RO tx Input Latch Local
Timestamp module 2
Local controller time corresponding to the input latch time in microseconds. It starts
at zero on device power-up. Mandatory if device has inputs. If device has no inputs
defined, this corresponds the time immediately prior to writing to input SM.
Local controller time corresponding to the input latch time in microseconds. It starts
at zero on device power-up. Mandatory if device has inputs. If device has no inputs
defined, this corresponds the time immediately prior to writing to input SM.
Index SI DataType NV Access PM Name
F840 0x01 UDINT x RW Data Units
0x02 V_STRING RW Password
Unit of the Value of the Analog Input Sensor Instance and all related parameters.
Trip Point Output All Instance
0x00220000
0xFD4E0000
0x00A10000
0x00E00000
Pascal
mbar
Torr
Counts (INFICON)
Subindex 0x03
Subindex 0x11
Subindex 0x12
4.7.12 Trip Point Output All
Subindex 0x01
4.7.13 Input Latch Local
Timestamp
Subindex 0x01
Subindex 0x02
4.7.14 Configure Device
Subindex 0x01
