The "active device warning details" parameter describes the warning state of the
complete device.
Index
SI
DataType
NV Access PM Name
F381
0x01 UDINT
RO
tx
Active Device Warning
Details Device
0x02 UDINT
RO
tx
Active Device Warning
Details Module 1
0x03 UDINT
RO
tx
Active Device Warning
Details Module 2
F382 0x01
UDINT RO tx
Active
Manufacturer
Warning Details
Active Device Warning Details Device(Index F381)
Bit 0…2
0
Bit 3
EEPROM exception
Bit 4…31
0
Active Device Warning Details Module 1 (Index F381)
Bit 0
0
Bit 1
Electronics warning
Bit 2…31
0
Active Device Warning Details Module 2 (Index F381)
Bit 0
0
Bit 1
Electronics warning
Bit 2…31
0
Active Manufacturer Warning Details (Index F382)
Bit 0
Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1…31
0
The "active device error details" parameter describes the error state of the
complete device.
Index
SI
DataType
NV Access PM Name
F383 0x01
UDINT RO tx
Active
Device Error Details Device
0x02
UDINT
RO
tx
Active
Device Error Details Module 1
0x03
UDINT
RO
tx
Active
Device Error Details Module 2
F384 0x01
UDINT RO tx
Active Manufacturer Error Details
Active Device Error Details Device (Index F383)
Bit 0
0
Bit 1
uP exception
Bit 2…31
0
Active Device Error Details Module 1 (Index F383)
Bit 0
0
Bit 1
Electronics failure
Bit 2…31
0
4.7.5 Active Device Warning
Details
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x01
4.7.6 Active Device Error
Details
Subindex 0x01
Subindex 0x02
