Chapter 4

Options

4-1

4.3 Full Rack Extender Installation

The Full Rack Extender option (PN 900-007) mounts a single SQC-122 into a full width
19” rack space.

Follow the steps below to assemble the extender and mount the SQC-122:

Remove SQC-122
Mounting Ear

Determine on which side of the SQC-122 you want to attach
the rack extender. If a rack mount ear is attached to the
SQC-122 on that side, remove the two 10-32 flat head screws
that mount the ear, then remove the rack mount ear.

Assemble the
Extender

Assemble the extender “box” using the eight 6-32 flat head
screws, two end panels, and two main panels. Thread two
socket head captive panel screws from the inside of one side
of the extender. Continue to thread the captive screws until
their threads are completely exposed on one side.

Attach the
Extender

Place the extender next to the SQC-122, and thread the
captive screws into the SQC-122 threaded holes that were
previously used to mount the rack ear. Tighten the captive
screws to secure the extender to the SQC-122.

Attach the
Mounting Ears

Attach the mounting ear previously removed from the SQC-122
to the extender using the same10-32 flat head screws. If rack
mount ears were not already attached to the SQC-122, attach
the other mounting ear also.

Mount the
SQC-122

Slide the entire assembly into an empty 5 ¼” high 19” rack
mount space. Secure the assembly with four 10-32 rack
screws (not supplied).

A. Material Parameters

Material

Density

ZFactor

Material

Density

ZFactor

Aluminum

2.73

1.08

Manganese

7.2

0.377

Aluminum Oxide

3.97

1

Manganese Sulfide

3.99

0.94

Antimony

6.62

0.768

Mercury

13.46

0.74

Arsenic

5.73

0.966

Molybdenum

10.2

0.257

Barium

3.5

2.1

Neodymium Fluoride

6.506

1

Beryllium

1.85

0.543

Neodymium Oxide

7.24

1

Bismuth

9.8

0.79

New

1

1

Bismuth Oxide

8.9

1

Nickel

8.91

0.331

Boron

2.54

0.389

Niobium

8.57

0.493

Cadmium

8.64

0.682

Niobium Oxide

4.47

1

Cadmium Selenium

5.81

1

Palladium

12

0.357

Cadmium Sulfide

4.83

1.02

Platinum

21.4

0.245

Cadmium Teluridium

5.85

0.98

Potassium Chloride

1.98

2.05

Calcium

1.55

2.62

Rhenium

21.04

0.15

Calcium Fluoride

3.18

0.775

Rhodium

12.41

0.21
