2.3 Defining a Process

A process is a sequence of film layers deposited to achieve a particular thin film
characteristic. A few processes, each consisting of a few layers, may be adequate for a
production facility. For research or laboratory use, the SQC-122 can store up to 25
processes to a total of 250 layers.

You should define each of the films that will make up the layers of the process before
starting process definition. See the previous section for instructions on defining films.

To define a process, select Process Menu on the main screen. A list of 25 processes
(or ) will be displayed. To define a new process, scroll to and press
Create. A new Process# is added to the list of existing processes (use the SQC-122
setup software to assign descriptive process names). Press Select, then Edit to
display the sequence of layers and films that comprise the selected process.

To add a layer, scroll to the desired location in the layer sequence, and press Insert
Layer
. Select a film for this layer from the list and press Enter. Once a film is assigned
to a process layer, you cannot change the film. Instead, cut the layer, then insert a new
layer and select the desired film. To edit a layer, highlight it, then press Edit.

Fnl Thk

Thickness Lim it

Start M ode

Start Thickness

Ram p Tim e

New Rate

Ram p2

Ram p1

Enabled

Disabled

3.5

0:00:30

0.150

Auto

0.400

0.500

En/Dis

En/Dis

kA

M an/Auto

kA

kA

RATE(A/s)

0.0

Layer Edit M enu

Exit to

M ain

Prev

M enu

Edit

THICKNESS(kA)

0.000

PO W ER( % )

0.0

M y Process 1 Layer 1 ->

Param eter

Value

Units

Init. Rate

5.0

A/s

Tim e Setpoint

0:01:00

h:m m :ss

h:m m :ss

A/s

Remember that most setup parameters are set in the Films Menu, and apply to every
instance where the film is used. The layer parameters pertain only to this instance of
the film, in this process.
