Chapter 1 Quick Start
1-7
1.5 Installation
W ARNING : Care should be exercised to route SQC-122 cables as far as practical from
other cables that carry high voltages or generate noise. This includes other line voltage
cables, wires to heaters that are SCR-controlled, and cables to source power supplies
that may conduct high transient currents during arc down conditions.
Rack
Installation The SQC-122 occupies a 5.25” high, half-rack space. An
optional installation kit is available to adapt to a full rack (see
Chapter 4). Install the unit in a 19” rack with the supplied
hardware.
Power
Connection W ARNING : Verify that the Voltage Selector Switch, located next
to the power switch, matches your mains supply voltage.
W ARNING : Verify that the power cable provided is connected to
a properly grounded mains receptacle.
Sensor Input
Connections Connect the BNC cables and oscillators from your vacuum
chamber feedthrough to the desired SQC-122 sensor inputs.
Source Output
Connections Connect the BNC cables from the SQC-122 output connectors
to your evaporation supply control input.
Digital I/O
Connections Refer to Appendix C for details on wiring digital I/O to the SQC-
122 Relay I/O connectors.
Computer
Connection If you would like to use the Windows software to collect data or
program the SQC-122, attach a 9 pin straight-thru cable from
the RS-232 connector to your computer’s serial port.
