28

Unison Paradigm BACnet Interface Object Reference Guide

5 Timed Event Handling

The Timed Event object type is somewhat special, in that new object instances can be

created by the user. In addition, existing "Timed Event" instances may be controlled,

modified, or even deleted.

This section describes, in detail, the BACnet client's process of creating, controlling and/or

deleting Paradigm system Timed Events using BACnet.

5.1Creating a New Timed Event Instance

Step 1:

Write the Timed Event "Name".

a: Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the BACnet standard property type:

"PROP_OBJECT_NAME" (decimal constant 77).

This property is a character string data-type.

Step 2:

Write the Timed Event "Override Name" or "Instance No".

a: Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the property type: "PROP_OVERRIDE_NAME".

This property is a character string data-type

Step 3:

Write the Timed Event "Space Name" or "Instance No".

a: Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the property type: "PROP_SPACE_NAME".

This property is a character string data-type.

Step 4:

Write the Timed Event "Begin Time".

a: Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the property type: "PROP_BEGIN_TIME_TYPE".

This property is an integer data-type with an enumeration value: 0 = Real, 1

= Astronomical, 2 = Duration.

b: Select one of the following actions, depending upon the value of this property:

If a Real Time Type:

• Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the property type: "PROP_BEGIN_TIME_HOUR". This is an

integer data-type with a value between 0 and 23.

• Then, perform a BACnet "Write Property" command on Instance Zero of the

Timed Event object, using the property type: "PROP_BEGIN_TIME_MINUTE".

This is an integer data-type with a value between 0 and 59.

If an Astronomical Time Type:

• Perform a BACnet "Write Property" command on Instance Zero of the Timed

Event object, using the property type: "PROP_BEGIN_TIME_ASTRO". This is

an integer data-type with an enumeration value: 0 = Sunrise, 1 = Sunset.

• Then, perform a BACnet "Write Property" command on Instance Zero of the

N o t e :

You may send either an Override Instance No., e.g. '321', or an Override Instance

Name.

N o t e :

You may send either an existing Space Instance No., e.g. '321', or an existing

Space Instance Name.
