14 Unison Paradigm BACnet Interface Object Reference Guide
1.13 ETC Holiday Object Type
ETC Holiday: BACnet Properties List
Is the Object Type Proprietary?
Yes
Does the Object Type contain any Proprietary Properties?
Yes, all but the first eight properties.
General Description of Object Type
The ETC Holiday object type is an ETC proprietary construct to encapsulate all the
properties of a Paradigm "Holiday" and its associated values. Paradigm holiday objects are
a named recurrence configuration that can be used to specify the recurrence of a Timed
Event object through its reference.
Each object instance for this "Object_Type" has an "Object_Identifier" that is unique for this
type and "Object_Name". The object may be created by the Paradigm Central Control
Server (P-CCS) based on the configuration using Paradigm LightDesigner, or by the
BACnet client, e.g. via "Create Object".
The "Present_Value" property will always have the objects ETC BCID (EtcBACnetCID); a
value that will always be a unique identifier within the storage of the BACnet interface
device and the P-CCS sub-system.
Property Identifier Property Datatype Property Brief Description
Object_Identifier BACnetObjectIdentifier Numeric code uniquely identifying this object
Object_Name CharacterString Alphanumeric string identifying this object
Object_Type BACnetObjectType Always: "OBJECT_HOLIDAY" or decimal 160
Present_Value EtcBACnetCID Unique 16 byte identifier assigned by P-CCS
Description CharacterString Alphanumeric description of this object
Recurrence EtcRecurrence Holiday's recurrence structure (see 2.12 ).
