5.6.1. Alarm Configuration
5.6.1.1. Access the Configuration Menu
Access the Protocol 3 controller Configuration Menu,(and sub-menus) by first ensuring the
controller is in Cycle Complete state (that is, not running), the control must be in its cycle
complete state (not running), if it is in that state
1. Press to stop the control before proceeding.
2. Simultaneously press and from Select a Mode to access the Main Menu.
3. From the Main Menu, navigate to Configuration Menu using and . Highlight
Configuration Menu and press .
4. At the Enter Configuration Mode Unlock Code prompt, enter the appropriate code
using and .
a. The default code is 10.
b. Press . To enter Configuration Menu .
5.6.1.2. Work with the Alarm Menu
The alarm menu allows you to configure the five customizable alarms along with configuring Hi
Limit settings. Table 16 describes the possible alarm settings (see Glossary of Terms for alarm
and parameter descriptions).
1. From the Configuration Menu , use and to scroll to and highlight Alarm
Configuration , then press to access the Alarm Configuration Menu.
2. Press to move forward through the different parameters in the menu, and
to enter the setting for a parameter, to move back through the parameters.
3. Press and together (simultaneously) to return to the Configuration Menu.
Table 16. Protocol 3 Possible Alarm Settings.
Alarm Selection
Parameter 1 Parameter 2 Parameter 3
Process High Alarm Value
(Degrees) Alarm Hysteresis (Degrees) Alarm Inhibit
