Protocol 3 Controller
Owner’s Manual
W
ORKING WITH
O
PERATING
M
ODES
Version 1.2
33
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Step # Protocol 3 Descriptor
Option
Description
Set Events 1-5: Press
or
to
toggle between Active and Inactive
11.
Hold
Choose when to release Hold: Operator
Key Press or Time of Day
Set Events 1-5: Press
or
to
toggle between Active and Inactive
12.
Loop
Set the number of times to loop current
segment
Specify how to move back to the host
segment after specified loops: Ramp
time, hold
Set Events 1-5: Press
or
to
toggle between Active and Inactive
13.
Join
Joins one profile to another: specified
profile immediately follows first profile
Navigate to and highlight to select from
among the current profiles
Set Events 1-5: Press
or
to
toggle between Active and Inactive
14.
End
Ends the segment and creates the profile.
Choose segment type from: Control Off,
Maintain Last Profile SP, Control Off with
Events
15.
Repeat
Sequence
Then End
Repeats sequence specified number of
times and then ends the segment and
creates the profile. Along with enter
numbering of times to repeat sequence,
choose from: Control Off, Maintain Last
Profile SP, Control Off with Events
5.3.1. Prepare for Profile Setup
From the Select a Mode screen, simultaneously press
and
to display the Main Menu
1. Navigate to and highlight
Profile Setup
.
2. Press
to display
Profile Setup Enter Profiler Mode Unlock Code
screen.
3. Press
to enter Unlock Code 0010.
4. Press
to display the
Profile Setup
screen.
5. Press
to move right and
to move left. Press
or
navigate through
numbers, uppercase letters and lower case letters.
6. After entering the profile name, press
as often as necessary to move to the next
screen.
