W ORKING WITH O PERATING M ODES Protocol 3 Controller Owner’s Manual
48 Version 1.2
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
Config-
uration
Menu Description Function Available Settings
Output Set rate of
change
toward
Segment
Target
Setpoint Output
Configuration

Output [1-5] Usage: Set Alarm, Event, Cycle
Complete, Running, or combinations

Linear Output Usage: Set the desired type for
any Linear Outputs fitted. From: 0-5, 0-10, 1-5, 2-
10V & 0-20, 4-20mA or 0-10VDC adjustable
Transmitter PSU. Parameters: Unused,
Retransmit PV, Retransmit SP, Control Power
Alarm
Set alarm
options and
high limit
values
Alarm
Configuration

Alarm [1-5] Usage: Set Alarm parameters:
Unused, Process High, Process Low, PV-SP
Deviation, Band, Signal Change Per Min, Input
Signal Break, Control Loop, % Memory Used.

High Limit Alarm Value: 1-1000

High Limit Alarm Hysteresis: Deadband on
“safe” side of alarm, through which signal must
pass before alarm deactivates.
Power
Fail
Recovery Set Control
Function on
Power
Failure Restart
Options

Manual Mode Recovery: Control Off, Restart
Manual Mode

Timer Recovery Method: Control Off, Restart
Timer, Continue Timer
Communi
cations Modbus
Communicat
ion Settings Set Up
Communicatio
ns 
Modbus Parity Bit: None, Even, Odd

Modbus Data Rate: 4800, 9600, 19200, 38400,
57600, 115200

Modbus Address: 1-255
Recorder Options for
recording
methods
and sample
time Start and stop
the Data
Recorder

Stop Recording:

Start Recording:

Recorder Status information: [see
configuration menu]

Delete Recording:
Clock Set date
and time for
internal
clock Clock
Configuration 
Date format: dd/mm/yyyy or mm/dd/yyyy

Set Date

Set Day of Week (Choose day of week)

Set Time (hh/mm/ss format)
Display Set options,
language,
screen color
inverted
display Display
Configurations 
Language: English or [Alternate language
chosen at time of order]

Display Color: Green to red on alarm, Red to
green on alarm, Green, Red

Invert Display: Standard or negative display

Display Contrast: 0-100
Lock
Code Set lock
code
options Lock
Configurations

Configuration: Off, 1-9999

Tuning: Off, 1-5000

USB Menu: Off, 1-7000

Recorder Menu: Off, 1-9999

Profile Setup: Off, 1-9999
Reset to
Defaults Factor
default
options Reset to
Factory
Configuration Reset All Parameters to Factor Defaults?
All Setting Will be Lost!
