6. UPC Five-digit Supplemental (Paperbacks)
7. EAN-8 (includes JAN-short)
8. EAN-13 (includes JAN-standard)
9. Industrial
2-of-5
10. Matrix 2-of-5
11. Interleaved 2-of-5, AIM USS-I 2/5
12. Codabar, 2-of-7, AIM USS-Codabar
13. Code 128, AIM USS-128
14. EAN Two-digit Supplemental
15. EAN Five-digit Supplemental
16. POSTNET
17. RM4SCC
18. Japan Postal Bar Code
19. Data Matrix (2D bar code)
20. MaxiCode (2D bar code)
21. PDF417 (2D bar code)
22. Australia Post Bar Code.
B.3 Description of the Supported Bar Codes
CODE 128
This bar code is only supported for Code C. This means that no support for Code A and Code B is
available as these contain characters not available for the interface.
Code C is paired digits. If an odd number is received, the last digit will be ignored in the bar code
generation. The digit will, however, be present in the HRI under the bar code.
EAN-128
This bar code supports paired decimal values above 99.
The EAN-128 barcode has the same parameters as the Code 128 - except for a fixed, initial code -
F1.
EAN 8/EAN 13 and UPC A
UPC/EAN are numeric bar code types with fixed length. The type is defined by the number of digits
used as input.
If 7 characters are received, a check digit is calculated and generated.
If 8 characters are received, the check digit is calculated and compared to the 8th digit. If the 8th digit
is valid, the code is sent, otherwise it will be rejected. Also applies to 12 or 13 digits for EAN13.
If 11 characters are received, an UPC A check digit is calculated and generated.
Start, stop and center codes are generated automatically.
INTERLEAVED 2 OF 5
Interleaved 2 of 5 is a numeric bar code type with automatic checking, numerical, variable length.
As the bar code requires an even number of digits the bar code will be completed with a leading 0
(zero), if an odd number of data is received
Checksum digits are normally not used.
Start, stop and center codes are generated automatically.
INDUSTRIAL 2 OF 5
