CHAMPION DH5000T Single Source Gas Manual User Manual
Page 49
41
Item Part
Description
Qty.
No. No.
1
419002
HOSE ASSY. 1/2" ID, X 16" LG. FLARE JIC
1
2
115101
CONNECTOR, MALE 1/2" NPT X 1/2" 37° FLARE BRASS
2
3
100171
BUSHING, REDUCING FACE 3/4" NPT X 1/2" NPT BRASS
2
4
102438
ELBOW, STREET 1/2" NPT X 90° BRASS
1
5
0509042
BOOSTER TANK, WELDED ASSEMBLY
1
6
108954
NUT, GRIP, 6-32 W/NYLON INSERT SST
2
7
110562
THERMOSTAT, FIXED, SNAP, 240ºF
1
8
100210
PLUG, 1/8" NPT SQ. HEAD, SST
1
9
109985
SEAL, ELECTRIC HEATER FLANGE
1
For Standard Model and Direct Vent Option Model
10
111233
HEATER, 7.5KW/10KW, 208/240V/60/1PH & 3PH
1
---
108579
HEATER, 9KW, 480V/60/3PH
1
For Condensate Removal Option Model Only
10
111232
HEATER, 10KW, 208/240V/60/1PH & 3PH
1
---
111234
HEATER, 10KW, 480V/60/3PH
1
11
106482
WASHER, LOCK 1/4" SPLIT SST
6
12
100003
NUT, PLAIN, 1/4-20 SST
6
13
107908
COVER, HEATER
1
14
111488
JUMPER, STRIP HEATER
1
15
109069
THERMOSTAT W/CAPILLARY, 110-195ºF
1
Booster Assembly - All Models and Options
