CHAMPION DH5000T Single Source Gas Manual User Manual
Page 123

115
~
6-1/2"
~12-9/32"
Scale 1/1
W
all Mount Bracket
Template
P/N 115074
For
Direct V
ent Option
and
Condensate Removal Option
Electrical
Control Box
Top W
all Mount Bracket
Bottom W
all Mount Bracket
1/4" Hole
1/4" Hole
1/4" Hole
1/4" Hole
See Reverse Side for Installation Instructions
For
m No. 115074_ rev
. A
P/N 900958 - Control Box Wall Mount Kit
