Chapter 6. Troubleshooting
Race Dash Users Guide 39
Symptom Possible Cause Remedy Notes
All sensors show
fixed high values Switch 1 (Peaks)
faulty Replace switch Disconnect switch. If
values return to
normal, replace switch.
Faulty switch wiring Check switch wiring Check wiring for short
between connector
pins K and H (earth)
Displays pressure
values too low and
temperature values
too high Low Battery voltage Recharge battery The system does not
give accurate readings
when voltage is below
9.0V
Sensor reading
incorrect Another gauge
connected to sensor Disconnect other
gauge It is not permissible to
connect a second
gauge
Gate value set too
high Change Gate RPM
in the display
configuration menu Peak values only
updated while the
engine RPM is greater
than the Gate value Peak values not
updated
Internal memory
battery dead Return unit to Auto
Meter for new
battery service Display shows
“!! MEM BATT !!”
warning on power up
Switch 1 faulty Replace switch Disconnect switch and
short its leads. If
display changes,
replace Switch 1
Otherwise check
wiring. Switch 1: Show
peak values does
not work
Faulty switch wiring Check switch wiring
for correct continuity Pin K to red S1 wire
less than 1.0 Ohm and
Pin K to Pin H (ground)
greater than 1M Ohm
Switch 2 faulty Replace switch Disconnect switch and
short its leads. If
display changes,
replace Switch 2
Otherwise check
wiring. Switch 2: Show last
alarm function does
not work
Faulty switch wiring Check switch wiring
for correct
continuity. Pin L to red S2 wire
less than 1.0 Ohm and
Pin L to Pin H (ground)
greater than 1M Ohm
Switch 3 faulty Replace switch Disconnect switch and
short its leads. If
display changes,
replace Switch 3
Otherwise check
wiring. Switch 3: Change
display layer
function does not
work
Faulty switch wiring Check switch wiring
for correct
continuity. Pin U to orange S3
wire less than 1.0 Ohm
and Pin U to Pin H
(ground) greater than
1M Ohm
