Chapter 5. Installing the Display System
Race Dash Users Guide 23
Switches
The four switches are used to control the functions of the Race
Dash.
The normal functions of the four switches are:
Switch Functions
Switch 1 1. Show Peak Values
2. Freeze speed on “HOLD” display (optional Corner Speed
feature only)
Switch 2 1. Show Last Alarm or
Enter Lap Time Memory mode (optional)
2. Clear Alarm
Switch 3 1. Change Display Layer
2. Clear Alarm
Switch 4 Manual Lap Marker
You can install the switches in any convenient location. When
installing the switches, you should take account of the following
considerations:
• The cable for each switch is approximately 16” in length
from the 19-way military connector.
•
It is important that the driver is able to reach Switch 3
easily in order to change the display and clear warning
messages after alarms. This switch is normally fitted on
the steering wheel.
• When you configure the system, you use Switches 1 to 4
for selecting the parameters and setting their values. These
switches should be installed so that you can reach them
easily when you are viewing the digital display.
