Chapter 6. Troubleshooting
Race Dash Users Guide 37
Chapter 6. Troubleshooting
Symptom Possible Cause Remedy Notes
Ignition is off Turn ignition on
Battery is dead Recharge or
replace battery
Display is dead
(no backlight,
nothing on
display, no green
dial lights)
Power connection
to B + or B - is
faulty Check if battery is
connected
correctly. Check
power lead
continuity
Battery is almost
dead Recharge or
replace battery Display is dead
(no backlight,
nothing on
display, green dial
lights on but dim)
or
!! LOW BATT !!
warning on
display
Power connection
to B + or B - is
faulty Check power lead
continuity
Battery is almost
dead Recharge or
replace battery Display flashes
and dial pointer
resets or vibrates
Power connection
to B + or B - is
faulty Check power lead
continuity
The power lead is
labeled B+ & B-
The battery positive
lead B+ is 19w conn
pin G.
B- is 19w connector
pin H.
Pressure sensor
has failed Replace sensor
Swap the fuel
pressure sensor to
confirm fault
Sensor
connections are
faulty Check for
continuity on
sensor lead.
A reading of 999 on
the display indicates
an open circuit
connection (pin D to
the red sensor lead
and pin H to the
black sensor lead)
The
!! LOW OIL P !!
message does
NOT appear on
power up.
The warning light
is not turned on.
Oil pressure alarm
disabled Check that the oil
pressure alarm is
set on
