2. System and Network Setup
79 AirLive WN-250R User’s Manual
Here are descriptions of every setup items:
Band (2): Select the band you want to use, all the wireless routers must use
the same setting.
SSID (3): This is the name of wireless router. You can type any
alphanumerical characters here, maximum 32 characters. SSID is
used to identify your own wireless router from others when there are
other wireless routers in the same area. Default SSID is ‘default’, it’s
recommended to change default ESSID value to the one which is
meaningful to you, like myhome, office_room1, etc.
Channel Select the channel you want to use, all the wireless clients
Number (4): must use the same setting.
Associated Clients (5): Click ‘Show Active Clients’ button, then an “Active Wireless
Client Table” will pop up. You can see the status of all active wireless
stations that are connecting to the access point.
Root AP SSID (6): In ‘Universal Repeater’ mode, this device can act as a station to
connect to a Root AP. You should assign the SSID of the Root AP
here or click ‘Select Site Survey’ button to choose a Root AP.
Site Survey (7): Click ‘Select Site Survey’ button, then a “Wireless Site Survey Table”
will pop up. It will list all available access points near by. You can
select one access point in the table and the router will join wireless
LAN through this access point.
After you finish the wireless setting, please click ‘Apply’ button, after you click ‘Apply’, the
following message will be displayed on your web browser:
