4. Appendix
97 AirLive WN-250R User’s Manual
3-1-1 Basic QoS Settings
Please follow the following instructions to set QoS parameters:
Please click ‘Qos’ menu on the left of web management interface and the following
message will be displayed on your web browser:
Here are descriptions of every setting:
Enable QoS (1):
Check this box to enable QoS function, unselect this box if you don’t
want to enforce QoS bandwidth limitations.
Total Download
You can set the limit of total download bandwidth in kbits. To disable
Bandwidth (2):
download bandwidth limitation, input ‘0’ here.
Total Upload
You can set the limit of total upload bandwidth in kbits. To disable
Bandwidth (3):
upload bandwidth limitation, input ‘0’ here.
Current QoS
All existing QoS rules will be displayed here.
Table (4):
