4. Appendix
121 AirLive WN-250R User’s Manual
Here are descriptions of every setup items:
Client PC Please input any text to describe this IP address, up to 16
Description (a): alphanumerical characters.
Client PC IP Please input the starting IP address in the left field, and input the
address (b): end IP address in the right field to define a range of IP addresses, or
just input the IP address in the left field to define a single IP address.
Client PC Please check all services you want to allow or deny this IP
Service (c): address to use, you can check multiple services.
Protocol (d): If the service you need is not listed above, you can create a new
service on your own. Please select TCP or UDP, if you’re not sure,
please select ‘Both’.
Port Range (e): Please input the port range of new service here. If you want to
specify port 80 to 90, please input ’80-90’; if you want to apply this
rule on a single port, just input the port number, like ‘80’.
Add (f): When you finish with all settings, please click ‘Add’ to save settings,
you’ll be brought back to previous menu, and the rule you just set
will appear in current IP filtering table.
If you want to remove all settings in this page, click ‘Reset’ button.
