4. Appendix
101 AirLive WN-250R User’s Manual
Remote Port Please input the range of remote (destination) port number that will
Range (f): be affected by this rule. If you want to apply this rule on port 80 to 90,
please input ’80-90’; if you want to apply this rule on a single port,
just input the port number, like ‘80’. If the remote (destination) IP
address and /or port number is universal, just leave it blank.
Traffic Type (g): Please select the traffic type of this rule,available options are None,
SMTP, HTTP, POP3, and FTP. You can select a specific traffic type
for this rule, if you want to make this rule as a IP address based rule
(apply the limitation on all traffics from / to the specified IP address /
port number), select ‘None’.
Protocol (h): Please select the protocol type of this rule, available options are
TCP and UDP. If you don’t know what protocol your application uses,
please try ‘TCP’ first, and switch to ‘UDP’ if this rule doesn’t seems
to work.
After you finish with all settings, please click ‘save’ button (i), you’ll be brought back to
previous menu, and the rule you just set will appear in current QoS table; if you did anything
wrong, you’ll get an error message when you click ‘Save’ button, please correct your input
by the instructions given by the error message.
If you want to erase all values you just entered. Click ‘Reset’
