AirLive ARM-104_v3 ADSL2/2+ Router 13
Following are the steps to properly connect your ARM-104_v3 ADSL2/2+ Router:
1. Turn off your computer/notebook.
2. Connect the ADSL port of your ARM-104_v3 ADSL2/2+ Router to the wall jack of the
ADSL/ADSL2/ADSL2+ Line with a RJ-11 cable.
3. Connect the Ethernet cable (RJ-45) from your ARM-104_v3 ADSL2/2+ Router (Switch) to the Ethernet
Adaptor in your computer.
4. Connect the Power adaptor to the ARM-104_v3 ADSL2/2+ Router and plug it into a Power outlet.
5. Turn on your computer.
6. Refer to the next section to setup or configure your system’s Network Adaptor.
The Power light will lit after turning on the ARM-104_v3 ADSL2/2+
Router.
Auto and self-diagnostic process might turn the LED indicators ON and
OFF during the process.
!
Use the Power Adaptor exclusively in combination with the equipment
supplied and do not use any other kind of power adaptor for the
equipment.
!
