2.3 Mounting
External Antenna Connection
Screw the antenna cable into the SMA antenna connector.
Caution
n Tighten the antenna connector gently with your hand – never use
wrenches!
Note
n For the best signal level fix the antenna in vertical position.
n Use signal strength indicator to find best place for antenna.
SIM Card Installation
Slot for SIM card is placed on the connector panel. Insert the SIM card to the slot with
contacts oriented to the front panel. Make sure that the card is locked properly.
Cautions
n Make sure that the UMTS/GSM provider’s SIM card is compatible with the
UMTS/GSM network supported by your 2N® SmartGate UMTS version.
n Select the required UMTS/GSM provider and SIM card services, such as
call forwarding, call barring, preferred networks, SMS service centre, etc.
in your mobile phone before inserting your SIM card in
2N
® SmartGate UMTS.
Power Supply Connection
2N® SmartGate UMTS is fed with 10-16V DC. Where a source other than the included
power supply adapter is used, the voltage range and polarity have to be maintained. See
technical parameters.
2N® SmartGate UMTS with battery option allows to support functionality in case of
power failure. For backup use four pieces of accumulators NiMh size AA. These
accumulators are not part of delivery. Put the accumulators to the battery holder on
the bottom side under the cover prior to installation. Polarity of accumulators is
marked inside of the battery space.
Warning
n Do not activate the power supply until the antenna is connected to
2N® SmartGate UMTS to avoid the UMTS/GSM module damage.
