Table of Programmable Parameters
3.2
78
IMSI lock
MSI (International Mobile Subscriber Identity) is a unique identification code for
SIM cards. Using the IMSI lock, the gateway locks a selected SIM card, rejecting
the other ones.
Capture
This menu helps you capture events on your gateway network elements. Packets
are saved into files dimensioned by the Pool parameter according to the Filter
and Interface selection. The files are saved in the .pcap format in a standard
network sniffer such as Wireshark.
Enabled
Enable saving into a file as set in the row.
Interface
Select the interface for trace capturing.
Setting options:
LAN, Ethernet, WiFi, UMTS, WAN (static), WAN (PPPoE)
Pool [kB]
Set the maximum file size. When this value is exceeded, a new file is created.
Filter
Select the filter for packet/protocol capturing. Select standard protocols such as
sip, tcp, udp, etc. If you select none, all events will be captured on the selected
interface.
Status
The parameter shows the count and total size of the files created. Push the
Refresh button in the lower part of the screen to refresh the parameter. A file
downloading option will be offered to you too.
Report
This menu provides the gateway LOG files. Export these files using the All
submenu. The other submenus include a ‘live view’ of this information.
Report - All
Here specify the content of the package to be generated after you click on Save. The
following information can be included:
