SECTION 9 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
9-18 – JLG Lift – 3121222
X030 Overload -
X031 Hourmeter -
X032 Hourmeter +
X033 Circuitbreaker Out
X034 Circuitbreaker In
X035 Gnd E-Stop In
X036 Gnd E-Stop Out
X037 Lift Switch E06P
X038 Key Common
X039 Key Ground
X040 Key Platform
X041 Lift Down Valve DT02P
X042 Steer Right Valve DT02P
X043 Lift Up Valve DT02P
X044 Steer Left Valve DT02P
X046 Platform Box DHD14P DHD14R
X047 Platform E-Stop Out
X048 Platform E-Stop In
X049 Joystick AMP09P
X050 Platform Module J1 MMF16P
X051 Platform Lift Drive Switch MMF03P
X052 Platform Alarm +
X053 Platform Alarm -
X054 Platform Horn Switch
X056 Inverter Switch Out
X057 Inverter Switch In
X058 Contactor Supply
X059 Contactor Out
X060 Power Module B-
X061 Power Module F1
X062 Power Module F2
X063 Left Motor Power Mod M1
X064 Power Module P
X065 Power Module B+ from Contactor
X066 Left Motor Power Mod M2
X069 Pump Motor +
X070 Pump Motor -
X071 Battery 1 + to Contactor
X072 Battery 1 -
X073 Battery 2 +
X074 Battery 2 -
X075 Battery Disconnect
X076 Battery 3 +
X077 Battery 3 -
X078 Battery 4 +
X079 Battery 4 - to Power Mod
X080 Right Motor Field Cross
Table 9-2. X-Connector ID Index
ID Description End 1 ID End 2 ID
