SECTION 7 - JLG CONTROL SYSTEM
7-10 – JLG Lift – 3121222
Table 7-2. Machine Configuration Programming Information (1001115626-B)
(Machines Equipped with ZAPI - 1001092456 Power Module Only)
Configuration
Digit
Setting
Range
Description
Market Default Setting
0 1 2 3 4 5
1
(Model #)
0
1
2
3
4
5 1230ES
1930ES
2030ES
2630ES
2646ES
3246ES
(Set to your applicable ES Model
0 through 5)
2
(Market *)
0
1
2
3
4
5 ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
JAPAN
0 - (ANSI USA)
(Set to your applicable market)
3
(Tilt Cutout)
0
1 NO - Drive and lift up not prevented while tilted (Ground and Platform Mode).
YES - Drive and lift up prevented while tilted (Ground and Platform Mode).
1 1 1 0 1 1
4
(Drive Cutout)
0
1 NO - Drive and lift up not prevented while elevated.
YES - Drive and lift up prevented while elevated.
1
5
(Charger Interlock)
0
1
DRIVE ONLY - Drive motion prevented while vehicle is charging.
DRIVE AND LIFT UP - Drive and lift up motions are prevented while vehicle is charg-
ing. Required for CE.
0 0 0 0 0 0
6
(Ground Alarm)
0
1
2
NOT INSTALLED - Vehicle alarm will function for Arm Guard (if enabled), Overload (if
LSS enabled, and as a horn.
DESCENT - Vehicle alarm will function for Arm Guard (if enabled), Overload (if LSS
enabled, as a horn and during Lift Down motion.
MOTION - Vehicle alarm will function for Arm Guard (if enabled), Overload (if LSS
enabled, as a horn and during Drive and Lift motion.
2 2 2 0 2 2
7
(Load)
0
1
2
NOT INSTALLED - Load Sensing System (LSS) is not fitted to the vehicle.
CUTOUT PLT - Load Sensing System (LSS) is fitted and Platform Controls are pre-
vented in the event of an Overload. Ground Controls remain functional. This is the
default setting for CE machines.
CUTOUT ALL - Load Sensing System (LSS) is fitted. Platform and GRound Controls
are prevented in the event of an overload.
0 1 0 1 0 1
8
(Battery)
0
1 FLOODED - Batteries are conventional lead-acid type.
AGM - Batteries are absorbed glass mat type.
0
9
(Footswitch)
0
1 NO - Vehicle is not fitted with a footswitch
YES - Vehicle is fitted with a footswitch
0 0 0 0 0 1
