SECTION 6 - JLG CONTROL SYSTEM
3121256 – JLG Lift – 6-21
6.9 MACHINE PERSONALITY SETTINGS/
FUNCTION SPEEDS
NOTE: Personality settings can be adjusted within the
adjustment range in order to achieve optimum
machine performance.
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON ANALYZER
2 ND LINE)
DESCRIPTION RANGE
DEFAULT VALUES
TIME RANGE (SEC)
(SEE SECTION 6.10
FOR MACHINE
ORIENTATION WHEN
SETTING SPEEDS)
1100S 1100SJP 1100S 11100SJP
DRIVE: ACCEL X.Xs Displays/adjusts drive acceleration 0.1 to 5.0 sec 2.0 2.0
DECEL X.Xs Displays/adjusts drive deceleration 0.1 to 3.0 sec 1.3 1.3
MIN forward XX% Displays/adjusts minimum forward
drive speed 0 to 35% 1 1
MAX forward XXX% Displays/adjusts maximum forward
drive speed 0 to 100% 90 100 44-48 44-48
MIN reverse XX% Displays/adjusts minimum reverse
drive speed 0 to 35% 1 1
MAX reverse XXX% Displays/adjusts maximum reverse
drive speed 0 to 100% 90 100 44-48 44-48
ELEV. MAX XX% Displays/adjusts maximum drive speed
NOTE: used when elevation cutout
switches are limiting maximum speed 0 to 50% 23 25 93-104 93-104
CREEP MAX XX% Displays/adjusts maximum drive speed
NOTE: used when creep switch on
pump pot is active 0 to 50% 26 35 79-87 79-87
STEER: max SPEED XXX% Displays/adjusts maximum steer
speed. 0 to 100% 100 100
