SECTION 6 - JLG CONTROL SYSTEM
3121256 – JLG Lift – 6-17
Table 6-2. Machine Configuration Programming Information
Configuration Digit Number Description
Default
Number
NOTE: The machine configuration must be completed before any personality settings can be changed. Changing
the personality settings first and then changing the model number of the machine configuration will cause
the personality settings to return to default
MODEL NUMBER:
1 1
2
3
4
1100S
1200S
1350S
1250A
2
ENVELOPE HEIGHT:
2 1
2
3
4
5
6
7
8
9
10
1350S: 135' MAX
1350S: 125' MAX
1350S: 120' MAX
1350S: 110' MAX
1200S: 120' MAX
1200S: 110' MAX
1250A: 125' MAX
1250A: 100' MAX
1250A: 80' MAX
1100S: 110’MAX
5
Note: The default settings (bold) will vary depending on the model selection with selection # 5 being the initial default setting.
MARKET:
3 0
1
2
3
4
5
ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
JAPAN
0
ENGINE:
4 1
2
3
DEUTZ F4 TIER1: Deutz BF4M1011 Diesel (Tier 1)
DEUTZ F4 TIER2: Deutz BF4M2011 Diesel (Tier 2)
DEUTZ ECM: Engine Control Module
3
