SECTION 6 - JLG CONTROL SYSTEM
3121256 – JLG Lift – 6-37
ENGINE:
START ACTIVE/NOT ACTIVE Displays status of the engine start circuit
AIR FILTER OP/CL Displays measured status of air filter by-pass switch. (Not dis-
played if MODEL NUMBER = 7 or 8)
BATTERY XX.XV Displays measured battery voltage
COOLANT XXXC Displays measured coolant temperature
OIL PRS LOW / OK or XXPSI Displays measured oil pressure
FUEL SELECT GAS/LP Displays status of fuel select switch. (Displayed if MODEL NUM-
BER = 2)
AMB. TEMP XXXC Displays measured ambient air temperature
FUEL LEVEL / / / FULL or LOW / OK Displays measured fuel level
XXXx rpm Engine RPM
Table 6-5. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2 nd
Line)
Description
