SECTION 6 - JLG CONTROL SYSTEM
3121256 – JLG Lift – 6-101
866 86 6 RIGHT FRONT STEER RIGHT VALVE - SHORT TO BAT-
TERY OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Right Front Steer Right
Valve.
867 86 7 RIGHT FRONT STEER RIGHT VALVE - SHORT TO
GROUND There is a Short to Ground
to the Right Front Steer
Right Valve.
868 86 8 RIGHT FRONT STEER LEFT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Right Front Steer Left
Valve.
869 86 9 RIGHT FRONT STEER LEFT VALVE - SHORT TO GROUND There is a Short to Ground
to the Right Front Steer Left
Valve.
8610 86 10 LEFT FRONT STEER RIGHT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Left Front Steer Right
Valve.
8611 86 11 LEFT FRONT STEER RIGHT VALVE - SHORT TO GROUND There is a Short to Ground
to the Left Front Steer Right
Valve.
8612 86 12 LEFT FRONT STEER LEFT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Left Front Steer Left Valve.
8613 86 13 LEFT FRONT STEER LEFT VALVE - SHORT TO GROUND There is a Short to Ground
to the Left Front Steer Left
Valve.
8614 86 14 RIGHT REAR STEER RIGHT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Right Rear Steer Right
Valve.
8615 86 15 RIGHT REAR STEER RIGHT VALVE - SHORT TO GROUND There is a Short to Ground
to the Right Rear Steer
Right Valve.
8616 86 16 RIGHT REAR STEER LEFT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Right Rear Steer Left
Valve.
8617 86 17 RIGHT REAR STEER LEFT VALVE - SHORT TO GROUND There is a Short to Ground
to the Right Rear Steer Left
Valve.
8618 86 18 LEFT REAR STEER RIGHT VALVE - SHORT TO BATTERY
OR OPEN CIRCUIT There is a Short to Battery
or an Open Circuit to the
Left Rear Steer Right
Valve.
8619 86 19 LEFT REAR STEER RIGHT VALVE - SHORT TO GROUND There is a Short to Ground
to the Left Rear Steer Right
Valve.
Table 6-6. Diagnostic Trouble Code Chart
DTC
Flash
Code
Sequence Fault Message Fault Description Check
