SECTION 6 - JLG CONTROL SYSTEM
6-42 – JLG Lift – 3121256
ENVELOPE: Displayed if MODEL NUMBER = 7 or 8
LENGTH XXXX.X Displays the current indicated boom length in inches.
ANGLE 1 XX.X Displays the current indicated boom angle 1 in degrees.
ANGLE 2 XX.X Displays the current indicated boom angle 2 in degrees.
A/D LNGTH XXXXX Displays the current indicated boom length in A/D counts.
A/D ANG1 XXXXX Displays the current indicated boom angle 1 in A/D counts or raw
angle if calibrated.
A/D ANG2 XXXXX Displays the current indicated boom angle 2 in A/D counts or raw
angel if calibrated.
CAN STATISTICS: CAN Statistics as detected by the Ground Module
RX/SEC XXX Displays the number of received messages per second
TX/SEC XXX Displays the number of transmitted messages per second
BUS OFF XX Displays the number of bus off occurrences
PASSIVE XX Displays the number of bus passive occurrences
Table 6-5. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2 nd
Line)
Description
