SECTION 6 - JLG CONTROL SYSTEM
3121256 – JLG Lift – 6-25
GROUND
MODE: U. LIFT UP XXX% Displays/adjusts fixed main lift up speed 0 to 100% 60 60
U. LIFT DN XXX% Displays/adjusts main lift down speed 0 to 100% 60 60
SWING XXX% Displays/adjusts fixed swing speed 0 to 100% 60 60
BASKET LVL XXX% Displays/adjusts fixed basket level
speed 0 to 100% 75 75
BASKET ROT XXX% Displays/adjusts fixed basket rotate
speed 0 to 100% 75 75
MAIN TELE XXX% Displays/adjusts fixed main telescope
speed 0 to 100% 60 60
TOWER TELE XXX% Displays/adjusts fixed tower telescope
speed
Not displayed if TOWER TELE=NO 0 to 100% 100 100
T. LIFT UP XXX% Displays/adjusts fixed tower lift up
speed
Not displayed if TOWER LIFT=NO 0 to 100% 100 100
T. LIFT DN XXX% Displays/adjusts fixed tower lift down
speed
Not displayed if TOWER LIFT=NO 0 to 100% 100 100
JIB (U/D) XXX% Displays/adjusts jib lift speed
Not displayed if JIB = 0 0 to 100% 60 60
JIB (L/R) XXX% Displays/adjusts jib swing speed
Displayed if JIB = 2 0 to 100% 70 70
GEN SET/
WELDER: ENGINE XXXX RPM Control generator/welder RPM. Not dis-
played if GEN SET/WELDER = 0 1200-2800 1800 1800
4150453-F
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON ANALYZER
2 ND LINE)
DESCRIPTION RANGE
DEFAULT VALUES
TIME RANGE (SEC)
(SEE SECTION 6.10
FOR MACHINE
ORIENTATION WHEN
SETTING SPEEDS)
1100S 1100SJP 1100S 11100SJP
