SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3121256
Chassis 1.5 TORQUE REQUIREMENTS
Table 1-6. Chassis Specifications
Maximum Travel Grade With boom in stowed
position (Gradeability) (1100SJP) 45%
Maximum Travel Grade With boom in stowed
position (Gradeability) (1100S) 30%
Maximum Travel Grade With boom in stowed
position (Side Slope) 5°
Turning Radius - 1100SJP (Axles Retracted)
Outside
Inside
22 ft. 6 in. (6.8 m)
14 ft. 5 in. (4.4 m)
Turning Radius - 1100SJP (Axles Extended)
Inside
Outside
8 ft. (2.4 m)
19 ft. 4 in. (5.9 m)
Turning Radius - 1100S (Axles Retracted)
Outside
Inside
35 ft. 6 in. (10.8 m)
25 ft. 3 in. (7.7 m)
Turning Radius - 1100S (Axles Extended)
Inside
Outside
10 ft. 11 in. (3.33 m)
27 ft. (8.2 m)
Max Tire Load 25,000 lbs. (11,340 kg)
Max Ground Bearing Pressure (1100SJP)
100 psi (7.03 kg/cm 2 )
Max Ground Bearing Pressure (1100S)
112 psi (7.87 kg/cm 2 )
Maximum Drive Speed 3.25 mph (5.2 kph)
Max. Hydraulic System Pressure 4600 psi (317 Bar)
Maximum Wind Speed 28 mph (12.5 m/s)
Maximum Manual Force 400 N
Electrical System Voltage 12 Volts
Gross Machine Weight (1100SJP) 40,900 lb. (18,552 kg)
Gross Machine Weight (1100S) 39,800 lb. (18,053 kg)
Table 1-7. Torque Requirements
Description
Torque Value
(Dry)
Interval Hours
Wheel Bolts 180 ft. lbs.
(252 Nm)
150
Swing Bearing Bolts 190 ft. lbs.
(260 Nm)
50/600*
Tele Cylinder
Regen Valve Mounting
Bolts 13 ft. lbs.
(18 Nm)
As required
Starter Solenoid
Contacts
Coil
95 in. lbs. (9.5 Nm)
40 in. lbs. (4 Nm)
As required
*Check swing bearing bolts for security after first 50 hours of
operation and every 600 hours thereafter. (See Swing Bear-
ing in Section 3.)
NOTE: When maintenance becomes necessary or a fas-
tener has loosened, refer to the Torque Chart to
determine proper torque value.
Table 1-8. Engine Torque Requirements
Description
Torque Value
Ft. Lb.s
Torque Value
Nm
Cylinder Head Cover 6 8.5
Cylinder Head Cover 6 8.5
Rocker Arm Adjustment
Screw 15 21
Intake Manifold 6 8.5
Air Intake Pipe 15 21
Exhaust Manifold 16 22
Oil Drain Plug 39 55
Oil Pan (sheet metal) 15 21
Oil Pan (cast) 22 31
Injection Line Attachment 21 30
Injection Valve Attachment 15 21
Lube Oil Filter Cartridge 19 27
