SECTION 1 - SPECIFICATIONS
3121256 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
1.2 TIRES
1.3 ENGINE DATA
1.4 SPECIFICATIONS AND PERFORMANCE
DATA
Dimensional Data
Table 1-1. Capacities
Hydraulic Tank 55 gallons (208 liters)
Fuel Tank 53 gallons (200 liters)
Hydraulic System 66 gallons (250 liters)
Table 1-2. Tire Specifications
Size 445/50D710
Load Range J
Ply Rating 18
Load Rating 26,500 lbs. @ 100 psi (12020 kg @ 6.9
Bar)
Foam Fill Poly urethane HD (55 Durometer) Foam
Max Tire Load 25,000 lbs. (11,340 kg)
Table 1-3. Deutz TD2011L04O Specifications
Type Liquid Cooled
Number of Cylinders 4
Bore 3.7 in. (94 mm)
Stroke 4.4 in. (112 mm)
Total Displacement 190 cu. in. (3108 cm³)
Compression Ratio 17.5
Firing Order 1-3-4-2
Output 75hp (56 kW)
Oil Capacity
Cooling System
Engine w/Filter
Total Capacity
5 Quarts (4.5 L)
11 Quarts (10.5 L)
16 Quarts (15 L)
Average Fuel Consumption 1.1 gph (4.1 lph)
Idle Engine RPM 1200
Mid Engine RPM 1800
High Engine RPM 2475
Table 1-4. Operating Specifications
Maximum Work Load - 1100SJP ( Capacity )
Unrestricted
Restricted 500 lb (230 kg)
1000 lb. (450 kg)
Maximum Work Load - 1100S ( Capacity )
Unrestricted 830 lb (365 kg)
Max.Vertical Platform Height 110 ft. (33.56 m)
Max.Horizontal Platform Reach (1100SJP) 75 ft. (22.9 m)
Max.Horizontal Platform Reach (1100S) 63 ft. 11 in. (19.5 m)
JibPLUS (1100SJP Only)
Length
Horizontal Motion
Vertical Motion
8ft. (2.44m)
180° working, 244° stowed
130° (+75/-55)
Jib (1100S Only)
Length
Vertical Motion
7ft. 3.5 in. (2.22m)
130° (+75/-55)
Table 1-5. Dimensional Data
Overall Width
Axles Retracted
Axles Extended
8ft. 2in. (2.49 m)
12ft. 6in. (3.81 m)
Stowed Height 10ft. (3.05 m)
Stowed Length (1100SJP) 34ft. 11in. (10.64 m)
Stowed Length (1100S) 44ft. 1.5in. (13.45 m)
Wheelbase 12ft. 6in. (3.81 m)
Tailswing 5ft. 6 in. (1.6 m)
Ground Clearance (Axle) 12 in. (30.4 cm)
Ground Clearance (Chassis) 25.5 in. (64.7 cm)
