7. Pre-operational Inspection
❑
Decal list
No
Part No
Description
Req
1
569295
Decal - Snorkel logo
2
2
0150448
Decal - Lanyard attachment
1
3
0072531
Decal - Electrocution hazard
1
4
12814
Decal - Hydraulic fluid
1
5
12833-2
Serial number plate
1
6
13228
Decal - MHP14AT logo
2
13228-1
Decal - MHP13AT logo
2
7
1843
Decal - Warning, New Zealand
only
1
9428
Decal - Electric hazard,
Australia only
1
8
300699
Decal - Operators checklist
1
9
45198-6
Decal - Do not disable limit
switch
6
10
45198-7
Decal - Wind speed rating
2
11
302559
Danger pinch point
2
12
12424
Decal - Towing speed
1
13
7856-45
Decal - Tyre pressure
2
14
0083426
Decal - Lifting & tie down
4
15
9223-3
Chevron warning stripes
(pieces)
8
16
013-0025
Decal - Warning with stabilizers
1
17
9751
Decal - New Zealand made logo
1
18
12545
Decal - Auto stabiliser operation
1
19
13111
Danger pinch point (small)
2
20
1772-002-
K
Decal - Fit boom cradle lock pin
1
21
13276
Decal - Emergency bleed down
valve
2
22
007-1925
Decal - Gasoline
1
23
0323897
Decal - Danger must not
operate
1
24
12423-215 Decal - Rated load
1
25
99228-1
Decal - Caution safety harness
1
26
015-0602
Decal - Danger keep clear of
descending boom
4
27
56242-6
Decal - Operator manual
enclosed
1
No
Part No
Description
Req
28
13205
Decal - 10. 9m height restriction
1
29
13183
Decal - Remove from towing
vehicle before operating
1
30
302950
Hydraulic oil level
1
31
13272
Decal- Manual stabilisers only
1
32
12617
Decal - Approved lift method
1
33
0080650
Decal - Shackle foot point
4
34
13373
Decal - Emergency lowering
1
