page 3-2 Rev C
■
Specifications TL39T
SPECIFICATIONS TL39T
Nominal working height 12.9m 42.3’
Maximum height to basket floor 10.9m 35.8’
Maximum outreach 6.4m 21.0’
Maximum width of base
Stabilisers retracted
Stabilisers extended 1.6m
3.6m 5.2’
11.8’
Safe working load (unrestricted) 215kg 474lbs
Platform size 1.15 x 0.70m 3.8’ x 2.3’
Construction Steel Steel
Travelling height 2m 6.6’
Overall length 4.7m 15.4’
Maximum towing speed 80km/h 50mph
Turntable rotation 540 o Non continuous
Trailer tongue weight (approximately) Less than 100kg Less than 225lbs
Maximum rated axle capacity 2000kg 4409lbs
Insulation rating Nil
(on standard models)
Weight 1460kg (Petrol model) 3218lbs (Petrol model)
❑ Recommended Hydraulic Oil
Shell Tellus 32 or Castrol AWS 32 or similar
3. Specifications
