Rev C page 3-1
3. Specifications
The Snorkel TL39T are boom supported elevating work platforms built to conform to Australian Standard
AS1418-10 Elevating Work Platforms.
NOTE:
For further details regarding lubricants, maintenance schedules and service please refer to the
Maintenance and Repair Parts Manual for this machine.
■
General Specifications
■
Specifications MHP14AT
SPECIFICATIONS MHP14AT
Nominal working height 13.5m 44.3’
Maximum height to basket floor 11.5m 37.7’
Maximum outreach 6.4m 21.0’
Maximum width of base
Stabilisers retracted
Stabilisers extended
1.6m
3.6m
5.2’
11.8’
Safe working load (unrestricted) 215kg 474lbs
Platform size 1.15 x 0.70m 3.8’ x 2.3’
Construction Steel Steel
Travelling height 2m 6.6’
Overall length 4.7m 15.4’
Maximum towing speed 80km/h 50mph
Turntable rotation 540 o Non continuous
Trailer tongue weight (approximately) Less than 100kg Less than 225lbs
Maximum rated axle capacity 2000kg 4409lbs
Insulation rating Nil
(on standard models)
Weight 1460kg (Petrol model) 3218lbs (Petrol model)
