General maintenance
A - Metalcal replacement (Models 22/23 XC)
Before replacing the metalcals, calibrate the plungers as per the calibration instructions. Also make sure that
the replacement metalcal is the correct one - check the part numbers.
> >
(1) Remove the red gauge
from the plunger. (2) Peel the metalcal off the
gauge, and remove all traces
of adhesive (use a solvent if
necessary). Wipe dry. (3) Replace the gauge and
set to the zero (fully down)
position. The locking pin at
the rear of the pump should
be engaged in the first of the
small holes.
> >
(4) Mark a line on the
gauge, level with the top of
the red handle. Use a fine
felt tip pen or pencil (or
scratch with a sharp object). (5) Remove the gauge from
the pump and peel off the
adhesive backing. (6) Carefully place the “0”
line (the line below the
numeral) of the metalcal on
the marked line of the gauge.
