Step 4 - Set the Gauges
> >
According to the setting
required, operate the spring
loaded button to release the
gauge. The red knob is for
the red gauge and the black
knob is for the black gauge With the appropriate button
operated, lift the gauge to
the reading required. The correct gauge setting is
shown when the figure
selected is fully exposed
above the RED handle and
the gauge release button
clicks firmly into place.
Step 5 - Charge the pump
>
With the gauges correctly
set, slowly and gently lift the
red pump handle until both
red and black handles are
against the appropriate
gauge knobs Continue to hold this for a
few seconds to ensure the
pump is correctly filled with
colorant.
If the colorant level is too low, air can be sucked into the pump. If this
occurs, return the handle to the zero position, add sufficient colorant, and
purge the pumps and valve (see chapter IV, step 2 & 3)
