General Information and Specifications
2.6
534D-9, 534D-10 & 544D
2.3
SPECIFICATIONS
2.3.1
Travel Speeds
2.3.2
Hydraulic Cylinder Performance
Note: Machine with no attachment or load, engine at full throttle, hydraulic oil above 130° F (54° C) minimum, engine
at operating temperature.
2.3.3
Electrical System
534D-9
534D-10
544D
2 Wheel Drive
18 mph (29 km/h)
19 mph (30,5 km/h)
19 mph (30,5 km/h)
4 Wheel Drive
9 mph (14,4 km/h)
9.5 mph (15,3 km/h)
9.5 mph (15,3 km/h)
FUNCTION
APPROXIMATE TIMES (seconds)
534D-9
534D-10
544D
Boom Extend (max boom angle)
15.3
14.5
18.3
Boom Retract (max boom angle)
12.8
13.4
17.6
Boom Lift
11.4
10.8
11.9
Boom Lower
8.6
8.1
9.2
Battery:
Type, Rating
12 BCI, Negative (-) Ground, Maintenance Free
Quantity
John Deere - 1 / Cummins - 2
Reserve Capacity
1,000 Cold Cranking Amps @ 0° F (-18° C)
Group/Series Group
31
Alternator (John Deere)
12V, 65 Amps
Alternator (Cummins)
12V, 95 Amps
